RevoCell® Awning Window Features
Microcellular PVC construction
Our RevoCell® awning window frames, brickmoulds, and sashes are insulated with billions of closed microscopic cells for superior energy efficiency. They are fusion-welded as a single unit, preventing the air from moving between the window parts.
Our RevoCell® awning windows feature a minimalist, slim profile that goes equally well with traditional and contemporary home designs.
4-1/2” fusion-welded frame
Our windows come standard on a 4-1/2” deep frame, which is stronger and more durable than the standard 3-1/4” sold elsewhere. The deeper frames give extra dimensional stability and strength. It also allows for a lower sash profiles to maximize the glass surface.
Our RevoCell® multi-lite awning windows feature structurally strong, seamless one-piece frames with integrated cross-mullions. It allows for more natural light to enter the interior, and offers better protection against drafts and water infiltration.
Dual and triple-pane insulated glass units
Two or more layers of glass are joined to create a sealed hollow chamber that acts as a thermal buffer. This minimizes direct heat transfer through glass, and helps prevent condensation and ice build-up. It also helps soundproof the interior, in conjunction with a high-quality cellular spacer.
Low-emissivity coated glass
An invisibly thin metallic coating is baked onto one or more of the glass pane surfaces, reflecting most of the heat in the form of infrared radiation back inside the home during winter and outside during summer, while letting most visible light pass through.
Argon gas filling
The air between the glass panes inside a thermal glass unit is replaced with argon. This inert, odourless gas is heavier than air, reducing convection between the panes and the associated heat loss through the insulated thermal glass unit. It also offsets water vapour to prevent condensation between the panes.
Ener-Edge® warm-edge spacer
Our thermal glass units use a cellular silicone warm-edge spacer with low thermal conductivity, minimizing heat transfer between the interior and the exterior. It also allows for the natural expansion and compression due to temperature changes without failing the seal between them.
Window sashes use three distinct continuous seals at the interface with the stationary frame and mullions. This stops drafts and the associated heat leaks through the awning window. The thermal glass unit is also sealed to the sash from both the inside and the outside.
PVC-cladded interior wood extension
Our awning windows accomodate a very securely fit interior wood extension cladded with a thick layer of no-maintenance PVC. It allows for the easy installation of blinds or other window treatments, and results in greater window strength and durability.
We use the highest grade PVC powder and fabrication techniques which result in a high gloss PVC finish. As a result, our windows are easier to clean, more durable, and won’t fade or yellow over time.
Integrated brickmould (optional)
A brickmould that is part of the window frame creates a superior window assembly that continues the insulation outside, also adding to the awning window strength. It doesn’t require capping – this means less chance of water and air leakage.
Low-profile nesting crank handle
The unique cover and handle design of our crank handle will differentiate your window from the rest. The full-flip folding handle recesses in the operator cover, giving your awning window a smooth, contemporary look, and minimizing interference with curtains and blinds.
NOVA® multi-point lock
The NOVA® Multi-point locking system is the most advanced and adaptable solution on the market. With a removable handle and cover, it offers optimized security, immense flexibilty, and effortless operation.
Robust awning operator
Our awning windows come with a high-performance awning operator which allows opening and closing large windows with 33% less effort than other operators of its kind. These operators feature a sealed housing to reduce water and air infiltration without the use of caulk or additional sealant.
“One-Click”, easy-to-remove screen
Our smooth-edge, easy-to-remove “One-Click” screens are the easiest screens to operate in the industry. With their durable yet elegant aluminium finish, these screens won’t warp or break down over time like some of the competition.
Durable standard colours
Our RevoCell® awning windows come in several standard colours that are engineered during the profile extrusion. Lighter tones are made with cap stock, meaning a layer of tinted PVC covering all exterior-facing surfaces. The darker tones are architectural-grade laminates that are UV reflective and extremely colourfast. Our standard colours are extremely UV and weather-resistant, and won’t peel, flake, or scratch like paint finishes.
Energy Efficient Awning Windows
The manufacturing process of all Energy Star® certified awning windows installed by Beverley Hills Windows and Doors are audited by an independent accredited certification body and approved by Natural Resources Canada. Our windows and doors carry the Energy Star® label showing their rating.
All of our RevoCell® mPVC windows meet and exceed the latest Energy Star designation criteria in Canada.
Awning Window Ratings
Here are the ratings on standard RevoCell® Awning windows, to CAN/CSA-A440.00 and NAFS-11 standards:
|Layers of glazing||2 (dual pane)||3 (triple pane)|
|Resistance to forced entry||F-40||F-40|
|Max size tested||34” x 81”||34” x 81”|
|Energy Rating (ER)||40||48|
|NRCan reference #||NR6681-35098310-ES5||NR6681-35098689-ES5|
|ENERGY STAR rated||High Efficiency||2021 Most Efficient|
Your choice of colour
Most homeowners get their replacement windows in stock white, which is a great all-around colour. But you don’t have to: we offer a comprehensive selection of durable factory finishes on RevoCell® windows, to suit any home style. And if these don’t work for you, custom paint is always an option.
RevoCell® Window Colours
Click Swatch to preview colour.
